SPECIFICATIONS

Model Number XTR102D XTR104D XTR122D XTR124D XTR152D XTR154D

Fs (free-air resonance, Hz) 25 26.5 27.1 28.3 23.8 24.5

Vas (equivalent compliance, cu.

ft.)

1.861 1.775 2.535 2.618 4.872 4.377

Vas (equivalent compliance,

liters)

52.690 50.253 71.785 74.140 137.950 122.822

Qms (Q, mechanical) 16.275 14.001 12.849 11.502 9.803 12.044

Qes (Q, electrical) 0.483 0.535 0.549 0.545 0.458 0.51

Qts (total driver Q) 0.469 0.515 0.526 0.520 0.412 0.495

Re (DC resistance, ohms) 3.93 7.62 3.82 7.37 3.91 7.20

Z (nominal impedance, ohms) 4 8 4 8 4 4

Efciency (1W @ 1M, db) 84.41 84.65 87.38 87.27 89.26 90.22

Xmas (one way linear excursion,

in.)

0.476 0.498 0.476 0.476 0.487 0.476

Xmas (one way linear excursion,

mm)

12.075 12.65 12.075 12.075 12.363 12.075

RMS POWER WATTS 500 500 600 600 750 750

NOMINAL POWER WATTS 1000 1000 1200 1200 1500 1500

MAX MUSIC POWER WATTS 2000 2000 2400 2400 3000 3000

Mms (total moving mass, grams) 143.83 134.21 177.45 157.55 297.18 292.37

Cms (mechanical compliance,

m/N)

0.282 0.269 0.194 0.201 0.151 0.142

BI (motor strength, Tesla-M) 13.55 17.82 14.51 19.47 21.99 28.05

Sd (effective radiating area, sq.

cm.)

363.05 363.05 510.71 510.71 804.25 804.25

Sd )effective radiating area, sq.

in.)

56.273 56.273 79.16 79.16 124.659 124.659

Frequency Range (Hz) 20-250 20-250 20-250 20-250 20-250 20-250

Energy Bandwidth Product

(EBP)**

42 44 44 45 35 31
