Orion XTR102D User Manual

SPECIFICATIONS
5
Model Number XTR102D XTR104D XTR122D XTR124D XTR152D XTR154D
Physical Dimensions
Speaker Displacement (cu ft) 0.05 0.05 0.077 0.077 0.143 0.143
Speaker Outer Diameter (inches/
mm)
10.67/271 10.67/271 12.56/319 12.56/319 15.43/392 15.43/392
Mounting hole diameter (inches/
mm)
9.10/230 9.10/230 10.91/277 10.91/277 13.59/345 13.59/345
Mounting depth (inches/mm) 5.31/135 5.31/135 6.22/158 6.22/158 8.54/217 8.54/217
Magnet Weight (Oz) 44.0 44.0 55.0 55.0 88+88 88+88
Basket diameter (inches/mm)
263.5/10.37 263.5/10.37 311.2/12.25 311.2/12.25 384.2/15.13 384.2/15.13
Recommended Enclosures
Typical sealed enclosure (cu. ft.) 1.00 1.00 1.50 1.50 2.00 2.00
Vented enclosure (cu. ft.) *** 1.00 1.00 1.50 1.50 3.00 3.00
Port tuning frequency (Hz) 40.00 40.00 40.00 40.00 36.00 36.00
Port diameter (inside, inches) 3.00 3.00 4.00 4.00 4.00 4.00
Port square equivalent (inches)
2.659x2.659 2.659x2.659 3.545x3.545 3.545x3.545 3.545x3.545 3.545x3.545
Port length (inches) 9.88 9.88 11.26 11.26 5.42 5.42

Orion XTR102D Specifications

General

Brand	Orion
Model	XTR102D
Category	Subwoofer
Language	English
