45
-
The wrapper unit is equipped with safety guards,
interrupng the wrapping cycle if the switches
(on top) is acvated.
If the safety switch is acvated, a message ap-
pear in the control box’s display. To connue, the
error message in control box must be acknowl-
edged and checked out.
Remove the object causing the stop. Move the
safety guard back in posion. The machine must
be restarted by a command in control box to con-
nue the interrupted process.
-
Speed regulaon
Use valve 53 (right) og 54 (le) to set the speed.
A height adjustment is normally not necessary .
Height seng:
The lm must enter the knife at mid secon if
possible, when being cut.
Knife arm, in upright posion:
Both rollers should easily be rolled.
Knife-arm, cung posion:
The outer roller on each arm should not be able
to roll/move. This to hold the lm while being cut.
Check that the knife is aligned between the two
rollers. Adjust the knife if necessary.
Valve:54
Valve:53
Valve:52
Roller, movable
Roller, locked
