The adjustment’s of the rear chamber belt is done
preferably from the right side of the machine.
Dismount the cover and safety net (picture 1) to get
access to the adjusng bracket’s and bolts seen in
picture 4.
The rear chamber belt might be adjusted on two loca-
ons. Either changing the bearing point of the tension
roller in picture 3, or the bearing point of the chamber
roller, shown in picture 1 on next side. Or a combina-
on of these two adjustments.
(Picture 2)
Adjusng the belt tracking is done by changing the
distance on the rollers bearing point in picture 3
By increasing the distance , the belt tracking will en-
ter towards in picture 2. When decreasing the dis-
tance the belt tracking will enter towards .
If the tracking of the belt is sll entering one of the
sides, the similar operaon must be carried out on the
le side bearings, but the . If reducing
the distance , the belt tracking will enter towards .
Cover
Safety net
Adjusng brackets, rear chamber belt
Bearing point (D), tension roller
