65
-
The length of the wrapper table’s belt must be adjust-
ed as shown in gure 1.
The belt tension can be changed by relocang the
roller. There are ve alternave holes to mount the
roller support.
Loosen the upper bolt to allow some movement on
the bearing housing. Dismount the lower bolt and pull
the roller backwards, replace the bolt in a suitable
hole. Both sides must be equal mounted.
If the belt tracking is incorrect, try to change locaon
(side) of the belts.
- -
Check the welding for cracks or deformaons.
Check all major bolt connecons and reghten if necessary.
Pay extra aenon to the bolts xing the drag bar and loop. (574 Nm)
All welding and drilling and other work being done to the frame, must be carried out with great cauon.
Please consult your local dealer or Orkel Compacon Ltd.
1 2
1 2 3
Fixing bolts, drag bar and loop
Correct length of wrapper table belt
Figure 1
