10 IM0973142 R1-4 IM0973142 R1-4 11
15. Disposal
Disassembly, removal and disposal. Local regulations for dealing with
waste must be followed when disposing of disassembled components or
entire units.
16. General terms and conditions
Orlaco Products BV is not liable for damage resulting from inadequate
servicing, incorrect usage or alterations made to the equipment without
informing the manufacturer in writing.
This installation manual has been made available by Orlaco Products
BV. All rights reserved. No part of this manual may be reproduced and/
or made public in printed form, in photocopy form or on microfilm, or in
any other way, without the prior written permission of Orlaco. This also
applies to the associated drawings and figures.
Orlaco reserves the right to make changes to components at any time
without informing customers beforehand or directly. All dimensions given
are for commercial purposes.
For information regarding repairs that is not covered in this manual,
please contact the Orlaco Products BV service department.
This manual has been prepared with all due care and attention. However,
Orlaco Products BV cannot be held responsible for any errors in this
manual or any consequences thereof.
FCC compliance statement:
The camera comes under section for commodity codes for electronic
equipment. This is known as “Harmonize code: 8525.30.9060” and the
importer can check off Block 2 on FCC form which states: “An FCC grant
of equipment authorization and an FCC ID are not required, but the equip-
ment complies with FCC technical requirements.”
Caution: Any changes or modifications in the construction of this device
which are not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment. Camera/Monitor
sets are visual aids and objects visible in camera/Monitor systems are
smaller or bigger than they appear on screen.
17. Release Notes
R1-0 New edition, October 2014.
R1-1 Picture added; valve sealing, October 2014
R1-2 RS485 PTZ cameras added, January 2015.
R1-3 Mounting safety cables added and panning PTZ changed from 340°
to 360°, January 2015.
R1-4 Power consumption changed, February 2016.
Remark:
This Manual is in place of IM0973140, IM0973141 and IM0973050.
Installation Manual Installation Manual
14. Additional zoom camera serial commands
V_ZOOM 0x07
V_ZOOM_STOP 0x00
V_ZOOM_TELE 0x27
V_ZOOM_WIDE 0x37
V_ZERO_LUX 0x01
V_ZEROLUX_ON 0x02
V_ZEROLUX_OFF 0x03
V_BACKLIGHT_COMP 0x33
V_BACKLIGHT_COMP_ON 0x02
V_BACKLIGHT_COMP_OFF 0x03
V_FOCUS 0x08
V_FOCUS_FAR 0x23
V_FOCUS_NEAR 0x33
V_FOCUS_STOP 0x00
V_AUTOFOCUS 0x38
V_AUTOFOCUS_ON 0x02
V_AUTOFOCUS_OFF 0x03
V_PRESET 0x3f
V_PRESET_SET 0x01
V_PRESET_RECALL 0x02
Zoom in:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZOOM> <V_ZOOM_TELE> <V_TERMINATOR>
Zoom out:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZOOM> <V_ZOOM_WIDE> <V_TERMINATOR>
Zoom stop:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZOOM> <V_ZOOM_STOP> <V_TERMINATOR>
Zerolux on:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZERO_LUX> <V_ZEROLUX_ON> <V_TERMINATOR>
Zerolux off:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZERO_LUX> <V_ZEROLUX_OFF> <V_TERMINATOR>
Backlight compensation on:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_BACKLIGHT_COMP> <V_BACKLIGHT_COMP_ON> <V_TERMINATOR>
Backlight compensation off:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_BACKLIGHT_COMP> <V_BACKLIGHT_COMP_OFF> <V_TERMINATOR>
Autofocus off:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_AUTOFOCUS> <V_AUTOFOCUS_OFF> <V_TERMINATOR>
Autofocus on:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_AUTOFOCUS> <V_AUTOFOCUS_ON> <V_TERMINATOR>
Focus near:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_FOCUS> <>V_FOCUS_NEAR <V_TERMINATOR>
Focus far:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_FOCUS> <>V_FOCUS_FAR <V_TERMINATOR>
Focus stop:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_FOCUS> <>V_FOCUS_STOP <V_TERMINATOR>
