Ormandy Group Breeze - Working Principles

2
TheBreezecomprisesofaSupapacPlateHeatExchanger,eithera3portor4portcontrolvalve,
primary pump, temperature sensor and PID controller, all mounted on a skid base.
Motorised3or4portcontrolvalves,allowrapidadjustmentoftheprimaryheatinputtomatch
changesinsecondaryhotwaterdemand.
TheBreezeissuppliedwithoutinsulationandthedesignensuresthattheoutlettemperaturedoesnot
fallbelowthesetpoint(60°Cdefault)butcanbeadjustedtosuitcustomerrequirementsand
consequentlyreducestheriskoflegionnairesdisease.
Providingtheclassofaccommodationanddetailsofthenumberandtypeofxturesareknown,
OrmandyRycroftwillbepleasedtorecommendtheoptimumsizeoftheBreeze.
With buer vessel to form a semi-instantaneous water heater
3 Port Valve
Primary
Flow
Primary
Return
Secondary
Inlet
Secondary
Outlet
Control
Stat
PHE
4 Port Valve
Primary
Flow
Primary
Return
Secondary
Inlet
Secondary
Outlet
Control
Stat
PHE
1.3 Working Principles
SecondaryFlow
Temperature Gauge
Pressure Gauge
Expansion
Vessel
Expansion
Relief
Valve
Lockshield
Valve
Cold Feed
Non-Return
Valve
Circulating
Pump
Secondary
Shunt Pump
Drain
Pressure/Temp
Relief Valve
Temperature
Sensor
Commissioning
Valve
Drain
Plug
Primary
Return
Actuator
Primary
Feed
Primary
Pump
