Hartley and Sugden
3.3.2. Sectional drawing for the Commodore Plus 5 & 6 (122 - 132)
Nb: The right and left lower and upper guides are locatable thanks to the square
cutting of 10 x 10 in the middle of the guide and on the upper edge of the panels.
A
DÉTAIL F
ECHELLE 1 : 4
