6.1. CONNECTION OF THE SAINT ROCH CLIMATIC REGULATOR
6.3.1. Components of climatic regulator HARTLEY & SUGDEN
E9.0300 E9.0631
GTCO
The control panelofthe Comm odorePlus boilers isprewiredto receive one ofthe optional climaticregulatorsE9.0300, E9.0631,
GTC0 in place of the control panel precut s.
Climatic regulator
delivered in option
Remotecontrol FBR2
delivered in option
Tank probe SPFS
delivered with the
regulator
Boilerprobe KFS
delivered with the
regulator
Departure probe VFAS
delivered with the
regulator
Externalprobe AFS
delivered with the
regulator
In order to install this regulation, it is necessary to interpose between the boiler connector block and the regulator, a
connection kit wired (9 poles) del iver ed with the regulator accessories. T he E9.0300 and E9.063 1 climatic regulator s may be
associated in option to a remote control with an ambient thermoresistor type FB R 2 connected on the regulator using 3 wires.
Moreover, in the event o f heating floor circuit, t he regulator requires a val ve se rvomotor SM 40 also availab le in option and
connected with 4 wires.
All components of the H artley & Sugden control are easily acce ssibl e and the connections easy al lowing a saving of time
appreciable fort the fitter.
