Hartley and Sugden
0-15-00 0-10005 1 boiler Commodore Plus 122 (5 inter)
0-15-00 0-10006 1 boiler Commodore Plus 132 (6 inter)
0-15-00 0-10007 1 boiler Commodore Plus 241 (7 inter)
0-15-00 0-10008 1 boiler Commodore Plus 242 (8 inter)
0-15-00 0-10009 1 boiler Commodore Plus 234 (9 inter)
0-15-00 0-10010 1 boiler Commodore Plus 244 (10 inter)
0-15-00 0-10011 1 boiler Commodore Plus 335 (11 inter)
0-15-00 0-10012 1 boiler Commodore Plus 345 (12 inter)
0-15-00 0-10013 1 boiler Commodore Plus 355 (13 inter)
0-15-00 0-10014 1 boiler Commodore Plus 455 (14 inter)
2-15-00 0-00000 1 Front element 1
2-15-00 0-01000 1 Rearelem ent 2
2- 1 5 - 00 0 - 0 21 0 0 1 Front intermediate section Commodore Plus 122- 132 3
2-15- 000 -02 100 2 Fron tinterm. section Commodore Plus 241 - 242 - 234 -244 3
2-15- 000 -0210 0 3 Frontinterm.section Commo dore Plus 335- 345- 355 3
2- 1 5 - 00 0 -02100 4 Front interm. section Commodore Plus 455 3
2-15 -000-03000 1 Fluegasbox 4
2-15-00 0-08100 1 Fuel naked door 5
1-30-31 0-00042 2 Front insulation furnace 6
1-30 -310-20020 1 Door insulation 7
1-30-24 0-60120 1 Ceramic fibre rope Ø 20mm siliconed 8
1-30-24 0-60410 acc. nr. Cord GPE Ø 10 mm 9
4-15 -000-730 00 1 Viewflame kit 1 0
1-30-38 0-90044 1 Pyrexview flame
2- 1 5 - 000 -02200 2 Interme dia temiddles ectionCo mmod or ePlus122 11
2- 1 5 - 00 0 - 0 2200 3 Intermediate middle section Commodore Plus 132- 234- 335 11
2-15- 000- 02200 4 Interm. middlesectionCommodorePlus241- 242-244 - 345 11
2- 1 5 - 00 0 - 0 2200 5 Interm. middle section Commodore Plus 355- 455 11
2-15 -000-02300 1 Intermediate rear section Commodore Plus 241 1 2
2- 1 5 -0 0 0- 0 2 3 00 2 Intermediate rearsection Commodore Plus 122- 132 -242 12
2- 1 5 - 00 0 - 0 2300 4 Intermediate rearsection CommodorePlus 234- 244 12
2-15- 000 -02 300 5 Interm. rearsection CommodorePlus 335- 345- 355- 455 12
1-60-70 0-10006 1 Draincock 3/4" 1 3
1- 7 0 - 64 0 - 3 41 0 1 1 Plunger3/4" - 100 14
3-99-00 0-02000 suiv. nr. Nipple 1 5
1- 6 0 - 20 0 - 5 00 1 5 1 Pipe injector3" 70 mm Commodore Plus 242 16
1-60- 200 -5001 6 1 Pipeinjector3" 140mm CommodorePlus 234- 244- 335 16
1-60- 200 -5001 7 1 Pipeinjector3" 190mm CommodorePlus 345- 355- 455 16
1-30-24 0-60114 1 Ceramic fibre rope Ø 14mm siliconed 1 7
Casing Commodore Plus
3-15-00 0-02000 2 Rear & front cover 1
3-15-00 0-08001 2 Upper rear & front fixation 2
3-15-00 0-08100 2 Right front & left rear fixation (lower) 3
3-15-00 0-08110 2 Left front & right rear fixation (lower) 4
3-15 -000-300 06 2 Stiffeningplate leftupper and lower panel 122- 132 5
3-15 -000-300 08 2 Stiffeningplate leftupper and lower panel 241- 242 5
3-15 -000-300 10 2 Stiffeningplate leftupper and lower panel 234- 244 5
3-15 -000-300 12 2 Stiffeningplate leftupper and lower panel 335- 345 5
3-15 -000-300 14 2 Stiffeningplate leftupper and lower panel 355- 455 5
3-15 -000-310 06 2 Stiffen ingplate right upperand lowerpanel 122 - 132 6
3-15 -000-310 08 2 Stiffen ingplate right upperand lowerpanel 241 - 242 6
3-15 -000-310 10 2 Stiffen ingplate right upperand lowerpanel 234 - 244 6
3-15 -000-310 12 2 Stiffen ingplate right upperand lowerpanel 335 - 345 6
3-15 -000-310 14 2 Stiffen ingplate right upperand lowerpanel 355 - 455 6
3-15-00 0-01001 1 Right rear panel 7
3-15-00 0-00001 1 Left rear panel 8
3-15-00 0-00000 1 Left front panel 9
3-15-00 0-01000 1 Right front panel 1 0
3-15-00 0-03100 1 Front plate 1 1
3-15-00 0-04000 1 Rear lower plate 1 2
3-15-00 0-05000 1 Rear upper plate 1 3
5-15-00 0-11000 1 Control panel plate 1 4
Code article Quantity Description of parts Ref.
