Hartley and Sugden
3. Insert the rear intermediate section ( attention with the visual code on the
section ).
4. Coat the section ribs with adhesi ve (supplied with the installation access ories)
and attach the lengths of sealing cord ( code n° 1-30-240-60410 / Ø 10mm ) in the
section ribs. Carefully degrease the double-taper nipples and bores. Coat the
nipples with compound ( supplied with the installation acc essor ies ) . Drive the
double-taper nipples int o the bores using a mallet or a hammer. It i s extremely
important t hat t he nipples should be driven in smoothly and exactly in t he centre
line of the bore.
5. Repe at the operation accor ding to the number of re a r inter, see tab le
page 3 in our exampleof illustration : 2 x.
