Ormandy SCP PLUS 3000 - TECHNICAL SPECIFICATIONS; DATA TABLE

3
2. TECNICAL SPECIFICATIONS
2.1 DATA TABLE
SCP Plus Model
3000
3500
4000
5000
6000
7000
Output (kW)
3000
3500
4100
5000
6000
7000
Dimensions & weight
A
2460
2460
2700
2700
2820
2820
B
2135
2135
2345
2345
2495
2495
C
3879
4379
4379
4879
5379
5879
D
2210
2210
2420
2420
2570
2570
E
1300
1300
1400
1400
1600
1600
F
3430
3930
3930
4430
4930
5430
G
1012
1012
1012
1262
1262
1262
H
1500
2000
2000
2200
2700
3200
J
1230
1230
1335
1335
1410
1410
K
1230
1230
1335
1335
1410
1410
Approx. dry weight (kg)
6300
6950
8200
8970
11280
12160
Efficiency based on net CV
Efficiency (%) @ 100% load
92.0
92.0
92.0
92.0
92.0
92.0
Efficiency (%) @ 30% load
94.0
94.0
94.0
94.0
94.0
94.0
Gas flow rate G20 (m³/h)
345
403
472
575
690
805
Combustion and flue data
Flue Gas Volume (m³/min)
130.5
152.2
178.3
217.4
260.9
304.4
Approx Flue Gas Temp. (ºC)
181
181
182
181
181
181
Comb. Chamber Resistance (mbar)
13.5
18.0
11.7
14.0
12.0
14.0
Water system
Hydraulic Resistance (11k) (mbar )
64.2
86.9
120.1
73.8
105.9
144.0
Hydraulic Resistance (20k) (mbar )
19.4
26.3
36.4
22.3
32.0
43.6
         k

16.2
18.9
21.7
27.1
32.5
37.9
        k

8.9
10.4
11.9
14.9
17.9
20.8
Water content (l)
4496
5212
6125
7335
9088
10066
Connections
Flue connection size (mm)
550
550
600
600
700
700
Flow & Return flanged connection
(mm)
200
200
200
250
250
250
Drain connection size (mm)
40
40
40
40
40
40
Safety valve size
50
50
50
65
65
65
