IG-267-EN versión 01; 07/04/2017
73
General Instructions
ekor.rpa
User configuration settings
9. User configuration settings
The current units have a large number of configuration
parameters and logical organisation is fundamental in order
to avoid errors in generating and translating the settings.
A tree structure for easier browsing can be achieved by
organising them by groups of different levels. The ultimate
goal is to help end-users to use the system correctly and
avoid ambiguities.
The format used for settings is based on XML (eXtensible
Markup Language). XML is a standard language for exchanging
structured information. This format gives the system the
scalability and flexibility necessary in order to continue
growing when new functions come about in the future.
The applications necessary to transform the data into
information or to share information are applications which
follow the rules of this same standard, thus improving
compatibility between the systems in a secure, reliable and
straightforward manner.
The system configuration settings files, at user level, are
made up of the following main groups:
• Local protection and automation settings
• Date and time settings.
• Remote communication settings.
• Automation settings for the facility.
9.1. Local protection and automation settings
The settings list is classified as follows:
• System information (INFORMATION). Read-only.
• System settings (SETTINGS)
- General settings (GENERAL_SETTINGS)
- Protection settings (PROTECTION)
- Automation settings (AUTOMATISM)
- Local port communication settings (COMMUNICATION)
System information (INFORMATION)
Node
Information
Type Designation Possible values Value by default
System
System Device ekor.rpa-100 Read Only
Equipment model Model 10202021/2022/2024/3021/3022/3024 Read Only
Range Range 110/120 Read Only
Type Type V/P Read Only
Type of coupling Coupling
One-core/Three-core/Calibrated/EVTC/
Busbar1/Busbar2/Busbar3/Busbar4/Busbar5/
Busbar6/cgm3/cosmos/etc.
Read Only
System serial number Serial_Number Aaabbccddd (family/year/week/unit) Read Only
System firmware version FW_Version aa.bb.cc (Version. Subversion. Revision) Read Only
Logic configuration identifier Logic_Configuration_Id. 6 digits with logic configuration identifier Read Only
Table 9.1. Information
System settings (SETTINGS)
General settings (GENERAL_SETTINGS)
Node
Settings
Type Designation
Range
Min. Max. Step (unit)
General
Network frequency Frequency 50 – 60 (Hz)
Time zone Time_Zone
Table 9.2. Settings
