1.
History
2
2. Purpose 2
3. General 2
4.
Packing
and
unpacking
the
ARTROMOT®
-
K1
5. Block diagram of the electronic
parts ARTROMOT®-K1
6. Bill of material for service parts ARTROMOT®-K1
7. Figure for bill of material
8. Special function Service menu for
ARTROMOT®-K1Comfort and Standard version
9. Special function Service menu for
ARTROMOT®-K1Classic
10. How to perform repairs
11. Checklist of safety and function test
ARTROMOT®-K1Comfort and Standard version
12. Checklist of safety and function test
ARTROMOT®
-
K1Classic
5
6
7
8
10
12
14
15
16
2
The
purpose
of
this
Se
rvice
Manual
is
to
help
you
make
simple repairs on the ARTROMOT®-K1. Only authorized
staff may perform repairs and maintenance as the manufac-
turer’s warranty and liability would otherwise be invalidated.
Only original parts may be used for servicing in accordance
with
the attached spare parts list.
3.1
Electronics,
connection
cables
1
2
3
4
No
plugs
may
be
connected
or
disconnected
while
the
unit is switched on. Always switch the ARTROMOT®-K1
off before connecting or disconnecting a plug.
The locks for spiral cable for the hand-held program-
ming unit have to be closed at all times.
When you assembling with electronic parts make sure
to use ESD (Electro Static Discharge) equipment.
Only original chip cards may be used. Insert the chip
cards so that ARTROMOT® is visible.
If you have to exchange any of the printed circuit boards
including the knee electronics, hand held programming
unit, motor control or power supply electronics you have
to perform a calibration.
Possible errors: Errors will be displayed on the hand-
held programming unit as follows shown:
Potentiometer
error:
Wrong angle information
-
>
C
heck
the
femur
settings
-> Replace knee electronics (Pos. 5)
-> Replace motor control (Pos. 25)
Failure
at
the
potentiometer:
Connection to the potentiometer is interrupted
-
>
Replace
the
spiral
cable
of
the
potentiometer
(Pos.
24)
-> Replace knee electronics (Pos. 5)
-> Replace motor control (Pos. 25)
Motor
driver
error:
The motor driver IC reported an error
-
>
Replace
motor
control
(Pos.
25)
Motor
error:
The motor did not turn properly
-
>
Replace
motor
control
(Pos.
25)
-> Replace the motor (Pos. 26)
Table
of
contents
2.
Purpose
1.
History
Revision
Date
Name
Change
1 10.02.2006 S. Herr Service Manual
created
2 14.07.2006 S. Herr Pos. 25,
chapter 10
3 14.08.2006 S.Herr Pos. 20,
Chapter 9, 12
3.
General
ERROR
XX
(XX
=
Number
of
the
error)
