Oromed ORO-N2 BASIC - Components of Your Blood Pressure Monitor; LCD Display Symbols

– 40 –

MONITOR

1 Systolic blood pressure
2 Diastolic blood pressure 3.Memory symbol
4 Heartbeat symbol
5 Average value symbol
6 Battery low symbol
7 Date/Time display
8 Pulse display
9 WHO indicator
10 Irregular heartbeat symbol
11 Movement error symbol
Cuff Connector Port
AC Adapter port
LCD Display
Memory
START/STOP
6 7
