Orthomate KAPP35 - Unfold the Steering Column

Orthomate™ - User Manual Page 5 of 12
©2017 StrideOn Ltd
Step 2. Unfold the steering column
A. Lift up the Steering Column (Figure 2A) until it clicks into position upright (Figure 2B).
B. Rotate the Locking Lever upwards towards the Steering Column into the open gap. (Figure 2B).
C. Turn the Release Lever clockwise until you feel it start to tighten (Figure 2C).
D. Push the Locking Lever down to the side, ensuring the lever is tight and the Steering Column secure.
(Figure 2D).
WARNING:
• Failure to ensure that the Steering Column is clicked into position (Figure 2B) and or not pushing the
locking lever down to secure the Steering Column (Figure 2D) will prevent proper locking and result in
serious injury.
• Never tamper with the Locking Lever.
3D
2A
2D
2C
2B
2A
