Ortofon 2M Red - Page 2

2M 78 / 2M Mono / 2M Red / 2M Blue / 2M Bronze / 2M Black /
2M 78 Verso 2M Mono Verso 2M Red Verso 2M Blue Verso 2M Bronze Verso 2M Black Verso
Output voltage at 1 kHz, 5cm/sec. 4 mV 4 mV 5,5 mV 5,5 mV 5 mV 5 mV
Frequency range at -3 dB 20-20.000 Hz 20-22.000 Hz 20-22.000 Hz 20-25.000 Hz 20-29.000 Hz 20-31.000 Hz
Tracking ability at 315 Hz
at recommended tracking force
70 µm 70 µm 70 µm 80 µm 80 µm 80 µm
Compliance, dynamic, lateral 18 µm/mN 18 µm/mN 20 µm/mN 20 µm/mN 22 µm/mN 22 µm/mN
Stylus type Spherical Nude Spherical Elliptical Nude Elliptical Nude Fine Line Nude Shibata
Tracking force recommended* 1,8 g (18 mN) 1,8 g (18 mN) 1,8 g(18 mN) 1,8 g(18 mN) 1,5 g (15 mN) 1,5 g (15 mN)
Load resistance* 47 kOhm 47 kOhm 47 kOhm 47 kOhm 47 kOhm 47 kOhm
Load capacitance* 150-300 pF 150-300 pF 150-300 pF 150-300 pF 150-300 pF 150-300 pF
*Recommended
