- 20 -

Removal of the belt system

• Loosen the strap.

• Thread the belt system out of the metal bracket at the back of the child car seat and guide

it through to the front (Fig. A).

• Remove the shoulder pads and the belt buckles from the belt.

• Fold the belt so that it can be stored behind the cover in the recess on the backrest (Fig. B).

• In order to remove the belt buckle, rst move the seat into its maximum lying position. Then

rotate the seat to the 90° position.

• Remove the cover and put it aside (Fig. C).

• Now thread the metal bracket of the belt buckle through the opening and then replace the

cover (Fig. D).

• Ensure that you retain all the parts that are removed in a safe place.

A B

C D
