Page 33
Installation and Operation Manual - Osburn 1700-I
ENGLISH
9.3
Minimum Masonry Opening and Clearances to Combustibles
CO
M
BU
S
TIB
LE
MA
NT
EL
S
HE
LF
CO
M
BU
S
TIB
LE
TO
P
S
URR
O
UN
D
CO
M
BU
S
TIB
LE
SI
DE
S
URR
O
UN
D
A
DJ
A
CEN
T S
IDE
W
AL
L
FL
OO
R P
RO
TE
CT
IO
N
J
I
H
Q
G
F
K
L
O
P
Figure 24: Masonry Opening and Clearances
MINIMUM CLEARANCES
F
16" (406 mm)
G
9" (229 mm)
H
27" (686 mm)
I
27" (686 mm)
Q
84" (213 cm)
MAXIMUM
THICKNESS
O
5" (127 mm)
P
12" (305 mm)
MINIMUM MASONRY
OPENING
J
21 ½" (546 mm)
K
16
27 ½" (700 mm)
L
12
⅞
(328 mm)
16
If a fresh air intake is required,
it is recommended to add at least 4" to the width of the minimum opening of the hearth.
32
34
