Page 59
Installation and Operation Manual - 2000
ENGLISH
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for your unit, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrade or availability. Contact an authorized dealer to obtain
any of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 AC01315 RIGID FIRESCREEN 1
2 30569 ROUND WOODEN HANDLE BLACK 2
3 30025 1/4-20 X 1/2" PAN-HEAD QUADREX BLACK SCREW 5
4 30187 STAINLESS WASHER ID 17/64" X OD 1/2" 2
5 30898 ROUND WOODEN BLACK HANDLE DULL BLACK FINISH 1
6 SE65024 HANDLE WITH LOCK KIT 1
7 OA10237 BLACK STEEL DOOR OVERLAY 1
7 OA10238 BRUSHED NICKEL STEEL DOOR OVERLAY 1
8 SE24285 CAST IRON DOOR WITH HANDLE AND GASKET 1
9 AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT 1
10 AC09185 DOOR LATCH KIT 1
11 30101 SPRING TENSION PIN 5/32"Ø X 1 1/2"L 1
12 SE65025 ARCHED DOOR WITH GASKET 18'' X 11-3/16'' 1
13 AC06400 3/4" (FLAT) X 6' BLACK SELF-ADHESIVE GLASS GASKET 1
14 PL65010 LEFT GLASS FRAME 1
15 PL65009 RIGHT GLASS FRAME 1
16 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
17 SE65003 AIR CONTROL DAMPER ASSEMBLY 1
18 30206 ZINC WASHER 5/16"ID X 3/4"OD 1
19 30506 SCREW PAN TORX TYPE F 1/4-20 X 1" BLACK 1
20 PL65873 LEFT OR RIGHT LEG SUPPORT 2
21 PL24218-02 NICKEL PLATED CAST IRON LEG WITH LEVELING BOLT 4
21 PL24218 BLACK PAINTED CAST IRON LEG WITH LEVELING BLOT 4
22 30050 LEVELING BOLT 3/8-16 X 1 1/2" 4
23 OA10228 BRUSHED NICKEL CAST IRON LEG KIT WITH ASH PAN AND SAFETY LID 1
23 OA10226 BLACK CAST IRON LEG KIT WITH ASH DRAWER AND SAFETY LID 1
24 30100 BLACK HEX NUT 1/4 - 20 12
25 30185 17/64" AA TYPE WASHER 8
26 SE65867 ASH PAN ASSEMBLY 1
27 24282 LEG NATURAL RAW CASTING WITHOUT PAINT 4
27 24282-01 BRUSH NICKEL PLATED CAST IRON LEG (BLACK PAINT IN THE BACK) 4
28 OA10236 BRUSHED NICKEL CAST IRON STRUCTURAL LEG KIT WITH ASH DRAWER 1
28 OA10235 BLACK CAST IRON STRUCTURAL LEG KIT WITH ASH DRAWER 1
29 PL65866 LEFT OR RIGHT LEG SUPPORT 2
30 PL65872 AIR CONTROL COVER 1
