Page #5 background image
5
1.2 Clearances to combustibles and floor protector
To install your appliance correctly, it is extremely important to respect all clearances to any combustibles
as indicated on your stove’s certification label.
Clearances to combustible materials
(see figure 1.3 to match each letter to a clearance)
CLEARANCES (SINGLE WALL PIPE)
CANADA USA
A
14" (356 mm) 16" (406 mm)
B
17" (432 mm) 18" (457 mm)
C
8" (203 mm) 12" (305 mm)
D
22" (459 mm) 24" (610 mm)
E
29" (737 mm) 30" (762 mm)
F
21" (534 mm) 25" (635 mm)
K
48" (1220 mm) 48" (1220 mm)
L
84" (213 cm) 84" (213 cm)
CLEARANCES (DOUBLE WALL PIPE)
CANADA USA
A
7" (178 mm) 12" (305 mm)
B
15" (381 mm) 17" (432 mm)
C
7" (178 mm) 7" (178 mm)
D
14" (356 mm) 19" (483 mm)
E
27" (586 mm) 29" (737 mm)
F
20" (508 mm) 20" (508 mm)
K
48" (1220 mm) 48" (1220 mm)
L
84" (213 cm) 84" (213 cm)
