Measurements of the Avantgarde Wheelchairs (in cm)
1. Overall length Min. Max.
SL 70 72,5 110,5
SL 80 68,0 103,0
TR 75,5 113,5
V 80,5 118,5
D (without footplate) 65,5 87,5
Teen 68,0 94,0
FL 76.0 114.0
➜
➜
Difference
Rear Wheel 22" +2,5/5 Rear Wheel 24", 26"
Teen-rear wheel 20" +2,5 Rear Wheel 22"
rear wheel - more foreward +2,3/ +4,6/ 6,9 rear wheel - more backward
+2,35 / 4,7 Teen - rear wheel
more backward
+13 / wheelbase extension
Teen +10,5
footplate – narrow +5 footplate standard
footplate – +4 footplate –
more backward +4 more forward
footplate – high +4 footplate – low
frame up to ST* 42 +4 frame from ST* 44
frame up to ST* 34 +2...+12 frame from ST* 46 (FL)
Difference
RH* 25 +5/10/15/20 RH 30/35/40/45
(Teen up to RH* 40)
push handles, standard +6…+16 push handles
height-adjustable
0…+10 adjustment range
+6…+20 Teen push handles
height-adjustable,
angled
0…+14 adjustment range
rear wheel – high +1.8/3.5/5.3/7 rear wheel – low
rear wheel 22" +2.5/+5 rear wheel 24"/26"
Teen rear wheel 20" +2.5 rear wheel 22"
2. Overall height Min. Max
SL, TR, V, D, FL 66,0 114,0
Teen 63,5 108,0
➜
➜
Difference
SB 32 +2/…/+18 SB 50
+2/…/+8 SB 36
wheel camber 0° +3/+5,5 wheel chamber 2.5°/5°
push ring attachment +2 push ring attachment wide
narrow +2,5 desk panels with
height adjustable armrest
(except Teen)
+1,5/+5 unilateral propulsion
rear wheel with drum
brake
3. Overall width Min. Max.
SL, TR, V, D, FL, 50,0 80,5
Teen 46,0 66,5
SB +18
SB +13,5 (with
transport wheels-
caster fork, narrow)
narrow)
SB + 15
(with transport wheels
caster fork wide)
➜
➜
4. Seat Height front Min. Max.
SL, TR, V, D, FL, 36,0 51,5
Teen
Difference
caster 3" +1,25/…/+5 caster 4"/5"/6"/7"
+3,2 caster 140 mm
upper bore +1,25/+2,5 lower bore hole
short fork +2/+3,5 long fork
caster wheel fitting for +4,5 without caster wheel fitting
low seat heights for low seat heights
➜
➜
5. Seat Height back Min. Max.
SL, TR, V, D, FL, 40,5 52,5
Teen 38,0 47,5
Difference
rear wheel – high +1,8/3,5/5,3/7 rear wheel – low
rear wheel 22" +2,5/+5 rear wheel 24", 26"
Teen rear wheel 20" +2,5 rear wheel 22"
➜
➜
6. Folding Measurement
(including rear wheels): from 26
13
