LCD-SW900 INSTRUCTIONS
P07 Reset ODO. Long press for 5s, ODO could be reset.
P08 Restore Factory Settings: Long press the for 5s, when the speed position
displays SSSS, namely the setting parameter restores factory setting value
P09 Background luminance. 1 is the darkest, 3 is the brightest
P10 Voltage grades. 24V, 36V, 48V. The original voltage is 36V.
P11 Sleep time. 0 is without sleep, other numbers stand for the sleep time (1-60 min).
P12 Driving mode.
0 is driven by PAS. Throttle is useless at this time.
1 is driven by Throttle. PAS is useless at this time.
2 is driven by PAS & Throttle. Throttle is useless at Zero Start status.
P13 PAS sensitivity. Range: 1-24
P14 PAS start strength. Range: 0-5
P15 Not implemented now.
P16 PAS magnet type. There are 3 types: 5, 8, and 12.
P17 The Current-limiting of Controller. The original Current is 12A. Range:1-20A
P18 Not implemented now.
5. Button Introductions
5.1 During riding, need change PAS/Speed grades, shortly press
5.2 During riding, need change data in Multi-function Area, shortly press ;
Long press , could switch status between MODE and ON/OFF;
Long press as a compound button, is mainly used for parameter setting, which could reduce
misoperation due to complicated operation.
(No compound button with short-time press, because it’s difficult to operate.)
5.3 Specific operation explanations
5.3.1 Change PAS grade
