Specifications
900-0112-01-00 Rev A 47
Table 19 48-Volt Inverter Settings
48 Vdc Inverter Default Minimum Maximum
Stacking
Stack Phase Master Master, OB Slave L1, 3p Classic B, or 3p Classic C
Power Save Level
Master Adjust Only
0 0 7
Slave Adjust Only
1 1 15
Sell
Sell RE Volts
52 Vdc 40 Vdc 60 vdc
Grid Tie Window User IEEE or User
Grid Tie Authority GridTie GridTie or No Sell
Calibration (Cal)
Vac Input Adjustment
236 220 254
Vac Output Adjustment
236 220 254
Battery Vdc Adjustment
2 0 4
These values are in digital counts, not volts. Lower counts stand for higher voltages, and higher counts mean lower
voltages. One count equals approximately 1 Vac. The range of adjustment is 15 Vac above nominal, and 17 Vac below
nominal.
These values are in digital counts, not volts. One count equals 0.4 Vdc. The range of adjustment is 0.8 Vdc above or below
nominal.
