Operation
900-0169-01-00 Rev B 41
Figure 11 Example of Three-Phase Stacking Arrangement (Three Inverters)
Figure 12 Example of Three-Phase Stacking Arrangement (Nine Inverters)
2.0 kVA 230 Vac
2.0 kVA 230 Vac
2.0 kVA 230 Vac
2.0 kVA
230 Vac
6.0 kVA
400 Vac
2.0 kVA
230 Vac
2.0 kVA
230 Vac
LOAD PANEL
OR
C Phase Master
B Phase Master
Master
C Phase
Master
B Phase
Master
Master
2.0 kVA 230 Vac
2.0 kVA 230 Vac
2.0 kVA 230 Vac
2.0 kVA 230 Vac
2.0 kVA 230 Vac
2.0 kVA 230 Vac
2.0 kVA 230 Vac
2.0 kVA 230 Vac
2.0 kVA 230 Vac
Slave
Slave
Slave
Slave
Slave
Slave
6.0 kVA
230 Vac
6.0 kVA
230 Vac
6.0 kVA
230 Vac
LOAD PANEL
18.0 kVA
400 Vac
OR
