OutBack Power FXR2012E - Page 77

Specifications
900-0169-01-00 Rev B 77
Table 24 FXR Settings for 48-Volt Models
Field Item Default Minimum Maximum
Auxiliary Output
Aux Control Auto Off, Auto or On
Aux Mode Vent Fan
Load
S
hed, Gen Alert, Fault, Vent Fan, Cool Fan,
DC Divert, GT Limits, Source Status, AC Divert
(Load Shed) ON: Batt >
56.0 Vdc 40.0 Vdc 72.0 Vdc
(Load Shed ON) Delay
0.5 minutes 0.1 minutes 25.0 minutes
(Load Shed) OFF: Batt <
44.0 Vdc 40.0 Vdc 72.0 Vdc
(Load Shed OFF) Delay
0.5 minutes 0.1 minutes 25.0 minutes
(Gen Alert) ON: Batt <
44.0 Vdc 40.0 Vdc 72.0 Vdc
(Gen Alert ON) Delay
0.5 minutes 0.1 minutes 25.0 minutes
(Gen Alert) OFF: Batt >
56.0 Vdc 40.0 Vdc 72.0 Vdc
(Gen Alert OFF) Delay
0.5 minutes 0.1 minutes 25.0 minutes
(Vent Fan) ON: Batt >
56.0 Vdc 40.0 Vdc 72.0 Vdc
(Vent Fan) Off Delay
0.5 minutes 0.1 minutes 25.0 minutes
(DC Divert) ON: Batt >
56.0 Vdc 40.0 Vdc 72.0 Vdc
(DC Divert ON) Delay
0.5 minutes 0.1 minutes 25.0 minutes
(DC Divert) OFF: Batt <
44.0 Vdc 40.0 Vdc 72.0 Vdc
(DC Divert OFF) Delay
0.5 minutes 0.1 minutes 25.0 minutes
(AC Divert) ON: Batt >
56.0 Vdc 40.0 Vdc 72.0 Vdc
(AC Divert ON) Delay
0.5 minutes 0.1 minutes 25.0 minutes
(AC Divert) OFF: Batt <
44.0 Vdc 40.0 Vdc 72.0 Vdc
(AC Divert OFF) Delay
0.5 minutes 0.1 minutes 25.0 minutes
Inverter Stacking
Stack Mode Master Master, Slave, B Phase Master, C Phase Master
Power Save
Ranking
Mode = Maste
r
:
Master Power Save Level
0 0 10
Mode = Slave:
Slave Power Save Level
1 1 10
Grid-Tie Sell
Offset Enable
Y Y or N
Sell Voltage
52.0 Vdc 44.0 Vdc 64.0 Vdc
Calibrate
A
C Input Voltage
X
0 Vac –7 Vac 7 Vac
A
C Output Voltage
X
0 Vac –7 Vac 7 Vac
Battery Voltage
X
0.0 Vdc –0.8 Vdc 0.8 Vdc
Grid Interface Protection Menu
Operating Frequency
Operating Frequency
X
50 Hz 50 Hz, 60 Hz
Stage 1 Voltage Trip
Over Voltage Clearance Time X
1.5 seconds 0.12 seconds 4.0 seconds
Over Voltage Trip X
252 Vac 240 Vac 300 Vac
Under Voltage Clearance Time X
1.5 seconds 0.12 seconds 4.0 seconds
Under Voltage Trip X
208 Vac 160 Vac 240 Vac
Stage 2 Voltage Trip
Over Voltage Clearance Time X
0.2 seconds 0.12 seconds 4.0 seconds
Over Voltage Trip X
264 vac 240 Vac 300 Vac
Under Voltage Clearance Time X
0.2 seconds 0.12 seconds 4.0 seconds
Under Voltage Trip X
196 Vac 160 Vac 240 vac
Frequency Trip
Over Frequency Clearance Time X
0.16 seconds 0.12 seconds 5.0 seconds
Over
Frequency Trip
60-Hz system
X
61.0Hz 60.2 Hz 65.0 Hz
50-Hz system 51.0 Hz 50.2 Hz 55.0 Hz
Under Frequency Clearance Time
X
0.2 seconds 0.12 seconds 5.0 seconds
Under
Frequency Trip
60-Hz system
X
57.0 Hz 55.0 Hz 59.8 Hz
50-Hz system 47.0 Hz 45.0 Hz 49.8 Hz
Mains Loss
Clearance Time
X
2.0 seconds 1.0 seconds 25.0 seconds
Reconnect Delay
X
60 seconds 2 seconds 302 seconds
Multi-Phase Coordination
Coordin. AC Connect/Disconn. N Y or N
Sell Current Limit
Maximum Sell
Current
FXR2348E
X
12 Aac 2.5 Aac 12 Aac
VFXR3048E 12 Aac 2.5 Aac 15 Aac
Model Select
X
Vented Vented or Sealed
