10. Technical Specifications
Image Sensor 5 Megapixel Color CMOS
Maximum Pixel Size 2560x1920 (5MP)
Lens F=3.1; FOV=50°; Auto IR-Cut-Remove (at night)
IR-Flash Range 36’-45’ (12m-15m)
Memory Card SD or SDHC Card, Maximum capacity 16GB
Internal RAM 32MB
Picture Size 5MP=2560x1920;3MP=2048x1536
Video Size 720x480/30fps, 640x480/30fps, 320x240/30fps
PIR sensitivity PIR with 3 sensitivity levels: High/Normal/Low
Operation Day/Night
Response Time 1s
Triggering Interval 1 sec. - 60min. programmable
Shooting Numbers 1~3 programmable
Video Length 5-60sec. programmable
Power Supply 8xAA recommended, 4xAA as emergency power
Stand-by Current < 0.3mA (<7mAh/day)
Power Consumption 200mA (+530mA when IR-LED lighted)
User Interface LCD display
Interface TV out (NTSC/PAL);USB;SD card holder;6V DC external
Security Strap; 1/4-20 attachment
Operating Temperature -20 - 60°C (Storage temp: -30 - 70°C)
Operating Humidity 5% - 90%
Security authentication FCC/CE/RoHs/WEEE
