Oval PC2201 - GENERAL SPECIFICATIONS; OUTLINE DIMENSIONS; STANDARD ACCESSORIES

E-935-1-E
11
5. GENERAL SPECIFICATIONS
ITEM DESCRIPTION
Generator Accuracy Crystal oscillator 6±0.0001MHz
Power Source
2-way - AC adaptor or internal batteries
AC adaptor: 100/V ac±10%, 50/60Hz
Internal batteries: UM-3 Ni-Cd batteries (700mAh)×6
Power Consumption 5VAmax.
Ambient Temperature 0 to＋40℃
Finish Black
Weight
2 kilograms, approx. (accessories, internal batteries inclusive)
Standard
Accessories
Soft case …… 1
Carrying strap …… 1
AC adaptor (9V dc, 200mA) …… 1
External connection cords (terminated with alligator clip and banana plug) …… Red 4, black 2
6. OUTLINE DIMENSIONS
7. STANDARD ACCESSORIES
HANDLESLOT
ACADAPTORSLOT
POWERSWITCHSLOT
SOFTCASE
1EA.
ACCESSORYCASE
CARRYINGSTRAP
1EA.
ACADAPTOR
1EA.
ALLIGATORCLIP
BANANAPLUG
RED:4
BLACK:2
EXTERNALCORD
SUP SIG SIG GATEOV OV
OUTPUT
INPUT
INPUTLEVEL
INPUTCOUNTER
OUTPUTCOUNTER
FUNCTION
OUTPUTWIDTH%SETTERRATINGSTOPRESETSTART
PULSECHE C K E R
PC2201
PRESET
FREQUENCY
RESET
POWER
DCIN
100
10
1
1K
10K
30
75
100
25
0
1
50
0.25
1.1
（ma）
PG30S
O.C
VOLT
PA11
P.A
PG30
PG20
OPTO
PERIOD
RATIO
105
15
COUNT
FREO
3
6
15
D.C
1.5
（V）
200 15 41
140
Unit：mm
