NOTE: The Operator will not
function unless the Safe-T-Beam®
System is installed and the
Force Controls are properly set.
1-PIECE BOOM HARDWARE EXPLODED VIEW
Assembly for 10' or 12' door includes:
1. Special “Close” Limit Switch with longer
wires.
2. 96" Emergency Release Cord (yellow)
3. Rail Support Kit
“PRO” ONLY
