Overhead door 1026 User Manual

Overhead door 1026

64 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Includes:

®

Remote Control

(For the ultimate in safety!)

• Safe-T-Beam

®

System must be

installed to close door.

•

For use only with sectional doors.

• Homelink

®

and Car2U

®

compatible.

• Easy programming.

For Answers and Assistance

1.800.929.3667

or visit

www.OverheadDoor.com

Homelink

®

is a registered trademark of Johnson Controls Technology Company.

Car2U

®

is a registered trademark of Lear Corporation.

Save this manual for future reference

Model 1026

Installer: Leave this manual with homeowner.

GARAGE DOOR OPENER

PN# 3642136534, 2/26/2010 REV.1

1026

Standard Drive

TM

Chain/Belt Openers

© 2008 Overhead Door Corporation. Overhead Door and the Ribbon logo are registered trademarks of Overhead Door Corporation. Standard

Drive is a trademark of Overhead Door Corporation. All other trademarks are the property of their rightful owners. Consistent with our policy of

continuing product improvements, we reserve the right to change product speciﬁcations without notice or obligations. R900-746

Table of Contents

Questions and Answers:

T
Theodore GalvanAug 14, 2025
Why Overhead Door Garage Door Opener remote control has less than 25 feet operating range?
- A
  Ashley StokesAug 15, 2025
  If your Overhead Door Garage Door Opener remote control has a short operating range, try these steps: relocate the remote control inside your car and point it at the garage door, reposition the door opener antenna, or replace the battery. Also, if the red LED blinks when you push the button, or doesn't come on, the battery is low and needs replacement.
S
Sheila LewisAug 18, 2025
What to do if Overhead door 1026 Garage Door Opener starts for no reason?
- S
  Scott LeAug 18, 2025
  If your Overhead Door Garage Door Opener starts by itself, consider these possibilities: a remote control was lost or stolen (erase all remote control codes from receiver memory and reprogram), the button on the wall button or remote is stuck, the close limit switch setting is incorrect, or the wires are shorted due to staples cutting the insulation. Repair or replace any damaged wires.
D
delacruzalbertAug 21, 2025
How to fix Overhead door 1026 Garage Door Opener that works from wall button, but not from remote control?
- C
  Christopher GarrettAug 21, 2025
  If your Overhead Door Garage Door Opener works from the wall button but not the remote control, try programming the remote control code into the receiver memory, or replace the remote control battery.
D
Douglas SnyderAug 25, 2025
Why Overhead Door Garage Door Opener door starts down, then stops before it’s closed?
- W
  Wayne AshleyAug 25, 2025
  If your Overhead Door Garage Door Opener door starts down, then stops before it’s completely closed, check the contact reverse, ensure the garage door isn't binding, look for shorted wires (repair or replace if staples have cut the insulation), and verify the close force adjustment.
E
ericmartinAug 28, 2025
How to troubleshoot Overhead door 1026 that does not run from wall button?
- D
  debra32Aug 28, 2025
  If your Overhead Door Garage Door Opener doesn't run from the wall button, check the power source by plugging a lamp into the outlet used for the power head. If the lamp works, the power source is okay. If not, check the fuse or circuit breaker. If power is okay, check the connections at the power head terminals and at the wall button. Also, check for reversed, broken, or cut wires, as staples can cut insulation and short wires. Repair or replace any damaged wires.
L
Lauren ParkerAug 31, 2025
What to do if Overhead Door Garage Door Opener door starts down, then stops and goes back up?
- M
  Maurice OliverAug 31, 2025
  If your Overhead Door Garage Door Opener door starts down, then stops and goes back up, or if there's a Safe-T-Beam® System malfunction, check the following: if it's a new installation, check the door arm position; check if the Safe-T-Beam® red LED is flashing; check the Safe-T-Beam® system for beam obstruction or misalignment of lenses (realign or replace sensors); check the close force adjustment; check the garage door for binding. If an operational problem exists and the opener will not run closed, hold the wall button down until the door is completely closed. As a last resort, disconnect the Safe-T-Beam® System from the opener and contact an authorized Overhead Door Dealer or Overhead Door Corporation.
M
mpotterSep 3, 2025
What to do if Overhead Door Garage Door Opener door starts up, but stops before it’s completely open?
- G
  Gary CummingsSep 3, 2025
  If your Overhead Door Garage Door Opener door starts up but stops before it’s fully open, ensure the door, opener, and springs are in good repair, properly lubricated, and balanced. Also, check the 'OPEN' limit setting and the 'OPEN FORCE' adjustment.
M
Michael DixonSep 7, 2025
What to do if Overhead Door Garage Door Opener runs, but door does not move?
- C
  Cassandra BoydSep 7, 2025
  If your Overhead Door Garage Door Opener motor runs, but the door doesn't move, ensure the carriage is engaged to the carriage slide by placing the carriage lever in the lock position. Also, check to make sure the chain is not broken or off its track. Finally, check the force adjustment; the door opener will not run for more than 30 seconds each way if the door does not move.
A
Andre HoweSep 10, 2025
Why Overhead door 1026 door will only run closed?
- Z
  Zachary RiosSep 10, 2025
  If your Overhead Door Garage Door Opener door only runs closed, check the door balance, condition, and door spring. Also, check the "OPEN FORCE" adjustment.

Overhead door 1026 Specifications

General

Horsepower	1/2 HP
Drive Type	Chain Drive
Remote Control	Yes
Safety Sensors	Yes
Battery Backup	No
Voltage	120V
Speed	7 inches per second

Summary

SAFETY INFORMATION

OVERVIEW OF POTENTIAL HAZARDS

Describes potential hazards and signal words used in the manual.

IMPORTANT SAFETY INSTRUCTIONS

Lists key safety instructions that must be read and followed.

SAFETY FEATURES

Safe-T-Beam® Non-Contact Reversing System

Describes the invisible beam safety system that reverses the door upon interruption.

Safe-T-Reverse® Contact Reversing System

Explains the system that reverses a closing door upon contact with an object.

Manual Emergency Release

PRE-INSTALLATION CHECK LIST

TYPICAL SECTIONAL DOOR INSTALLATION

IMPORTANT INSTALLATION INSTRUCTIONS

1 OPENER ASSEMBLY

RAIL ASSEMBLY

POWER HEAD & RAIL ASSEMBLY

Assembly for CHAIN DRIVE OPENER

Assembly for BELT DRIVE OPENER

2 INSTALLATION

HEADER AND DOOR MOUNTING BRACKETS

Guidance on finding and mounting the header and door brackets securely.

MOUNTING THE OPENER

DOOR BRACKET

INSTALL DOOR ARMS

3 WALL BUTTON INSTALLATION

4 SAFE-T-BEAM® SYSTEM INSTALLATION

5 CONNECTING TO POWER

INFRARED PROTECTION FUNCTION

6 DOOR LIMITS

SETTING & TESTING OPEN/CLOSE LIMITS

KEYED EMERGENCY RELEASE

UP/DOWN FORCE

ERASE/RESET - OPEN/CLOSE TRAVEL LIMIT

CONTACT REVERSE TEST

7 PROGRAMMING REMOTE CONTROLS

LOST OR STOLEN REMOTE

10 MAINTENANCE

ROUTINE MONTHLY MAINTENANCE

TROUBLESHOOTING GUIDE - OPERATION

TROUBLESHOOTING GUIDE - POWER HEAD LED
