4
Things to consider if you are planning to “do-it-yourself.”
Whether you are replacing an existing garage door operator or installing an operator in your
garage for the first time, there are some pre-installation issues which need to be addressed.
They are as follows:
The Overhead Door Corporation recommends that you read and fully understand all
information and instructions contained herein before choosing a
“
do-it-yourself
”
installation. Any questions should be directed to the Overhead Door Corporation or an
authorized Overhead Door Dealer.
6
To avoid damage to your door and/or
operator, make sure you disable any door
locks prior to installing your operator
.
PRE-INSTALLATION CHECK LIST
FOR HELP-1.800.929.3667 OR OVERHEADDOOR.COM
1
Check your ceiling where the power
head of your new unit will be mounted.
Plan how you will be mounting the power head.
It is possible that ceiling joists may not be in the
exact position needed with respect to the garage
door operator
. It may be necessary to add an
additional bracket and
fasteners (not included
with your new door operator kit).
2
Check the wall directly above the garage
door
. The door operator’s header bracket
must be securely fastened to this wall. Ensure
that the structure will provide a strong mounting
location.
3
Check to see if the mounting location
for the Safe-T-Beam
®
System (STB) is
clear from obstruction and has a wood
surface available for attaching the STB
brackets
. The brackets may be attached to
concrete if necessary but extra tools and special
fasteners (not supplied) will be required.
NOTE: 1-1/2" STB bracket adapters are available
through your local Overhead Door Dealer.
4
Is your garage door made of
light-weight steel, aluminum, fiberglass
or glass panels
? Additional support bracing
must be added to these type doors. If this is the
case, please contact the door distributor or
manufacturer so that they can furnish you with a
“bracing kit.”
7
Ensure that your door is properly balanced
and moving freely. SEE WARNING BELOW.
If your door sticks, binds, or is out of
balance, have it adjusted by a professional.
Door springs, cables, pulleys, brackets and
associated hardware are under extreme
tension and can cause serious injury or
death.
WARNING
(
The issue numbers below refer to the circled numbers in the illustrations on page 5.
)
8
(NOT SHOWN) If your garage does not have
a separate entry door, you should consider
an emergency release kit
(
GER-2
)(
page 34) for
installation on your garage door
. Contact Customer
Service or visit www.overheaddoor.com.
DO NOT USE AN EXTENSION CORD!
Extension cords can cause dangerous
overheating conditions.
DO NOT USE A PORTABLE GENERATOR!
This product is designed to operate on
standard house current. Do not use
alternate power supplies.
WARNING
5
You need a 110-120 Volt power supply
available
. The outlet should be no more than
3 feet from the power head once it is mounted. (The
cord is 4 ft. in length.) SEE WARNING BELOW.
Homelink
®
is a universal
transceiver (a combined
transmitter and receiver), that provides a
convenient way to replace up to three hand-held
radio-frequency (RF) transmitters used to
activate devices such as gate operators, garage
door openers, entry door locks, security sys-
tems and even home lighting. Additional
HomeLink
®
information can be found at:
www.homelink.com or by calling 1.800.355.3515
.
