overstock S-9182 - Part List; Hardware List

ITEM NO.: S-9182
REVISED SEPT 14, 2018
Printed in Vietnam
- 3 -
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Chair Back
1
B
Seat Frame
1
C
Chair Seat
1
D
Front Leg
(L-R)
2
E
Side Stretcher
(L-R)
2
F
Front Stretcher
1
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Short Bolt
(M6 x 40mm)
3
2
Medium Bolt
(M6 x 60mm)
4
3
Long Bolt
(M6 x 80mm)
4
4
Long Screw
(M4 x 50mm)
6
5
Short Screw
(M4 x 35mm)
4
6
Lock Washer
(6.5 x11mm)
11
7
Flat Washer
(6.5 x19mm)
11
8
Allen Key
(M4 x 30mm x 110mm)
1
