ITEM NO.: S-9182
REVISED SEPT 14, 2018
Printed in Vietnam
- 4 -
P
STEP 1
Attach seat frame (B) to the back (A) with bolts (1) and (3), and washers (6) and (7) as shown below.
Tighten with Allen key (8).
Note: DO NOT tighten any of the bolts, until the stool is assembled, then put on a flat level surface to
make sure the stool is level and then tighten the bolts.
STEP 2
Attach front legs (D) to the seat frame with bolts (2), and washers (6) and (7) as shown below. Tighten
with Allen key (8).
Attach front stretcher (F) between front legs, and then attach side stretchers (E) to front and back
legs with screws (4) as shown below. Tighten with a screwdriver.
