OWC EXPRESS 4M2 User Manual

OWC Express 4M2
Device Setup
3
2.1 Assembly
Please follow the instructions below to install one or more M.2 SSDs into the OWC Express
4M2 enclosure. If you have any concerns please contact our technical support team.
1. Remove the Express 4M2 from its packaging then loosen
the two thumbscrews on the back of the device until they
spin freely.
2. Holding the front cover, carefully slide the
inner chassis out of the outer enclosure.
3. Set the outer enclosure aside. Notice there is a fan
housing axed to the inner chassis; this covers the area
where SSDs are installed, so it will need to be removed
temporarily. Set the inner chassis on your work surface so
the fan is facing upward before proceeding to Step 4.
DEVICE SETUP

OWC EXPRESS 4M2 Specifications

General

Material	Aluminum
Fan diameter	60 mm
Product type	SSD enclosure
Certification	CE, FCC
On/off switch	Yes
Product color	Black
LED indicators	Activity, Power
Number of fans	1 fan(s)
Storage drive size	M.2 \
Maximum storage capacity	16 TB
Number of storage drives supported	4
Supported storage drive interfaces	PCI Express 3.0
USB version	Thunderbolt 3
USB connector type	USB Type-C
USB ports quantity	3
Chipset	Alpine Ridge DSL6540
Data transfer rate	40 Gbit/s
Power source type	AC, DC
AC adapter frequency	50-60 Hz
AC adapter input current	2 A
AC adapter input voltage	100-240 V
AC adapter output current	6 A
AC adapter output voltage	12 V
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 10 x64
Operating altitude	-304.8 - 12192 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	11.3 mm
Width	13.6 mm
Height	6 mm
Weight	800 g
