OWC EXPRESS 4M2 User Manual

OWC Express 4M2
Device Setup
5
7. Ax each drive’s mounting screw as shown.
Repeat Steps 6 and 7 for each SSD being
installed. The image below-left shows what
the device looks like with all four M.2 SSDs
installed. Note that you can use dierent
brands and capacities of SSD if you wish.
8. Take the fan housing you removed in Step 4 and place it
atop the inner chassis again, making sure that the screw
holes on the housing align with the screw holes on the inner
chassis. Re-ax the two fan housing screws (red arrows),
then reseat the power connector (green arrow).
9. Align the inner-chassis with the track in
the outer enclosure, then slide the inner
chassis into the enclosure. If there is
resistance do not force the inner chassis.
Remove it, re-align it, then try again.
10. Tighten both thrumbscrews on the back of the device
until you feel resistance. This completes the assembly
process. You can now connect the device to power and
your host computer with the included cable.

OWC EXPRESS 4M2 Specifications

General

Material	Aluminum
Fan diameter	60 mm
Product type	SSD enclosure
Certification	CE, FCC
On/off switch	Yes
Product color	Black
LED indicators	Activity, Power
Number of fans	1 fan(s)
Storage drive size	M.2 \
Maximum storage capacity	16 TB
Number of storage drives supported	4
Supported storage drive interfaces	PCI Express 3.0
USB version	Thunderbolt 3
USB connector type	USB Type-C
USB ports quantity	3
Chipset	Alpine Ridge DSL6540
Data transfer rate	40 Gbit/s
Power source type	AC, DC
AC adapter frequency	50-60 Hz
AC adapter input current	2 A
AC adapter input voltage	100-240 V
AC adapter output current	6 A
AC adapter output voltage	12 V
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 10 x64
Operating altitude	-304.8 - 12192 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	11.3 mm
Width	13.6 mm
Height	6 mm
Weight	800 g
