OWC USB-C DOCK User Manual

OWC USB-C Dock Introduction
3
1.5 Rear View
1. USB 3.1 Gen 1 Standard-A ports — connect additional USB 3.1 devices
here. These ports are backward compatible with USB 2.0 devices. The high-
powered port can be used to recharge mobile devices.
2. USB 3.1 Gen 1 Type-C port — if your USB 3.1 device has a cable with a
Type-C connector on the upstream end, you can connect it to this port.
3. Gigabit Ethernet port — connect an Ethernet cable here to access a wired
network. Ethernet driver required for OS X. See Section 2.2 – Usage Notes
for more details.
4. USB 3.1 Gen 1 Type-C Computer Link — connect this port to your computer.
5. Mini DisplayPort — connect a Mini DisplayPort enabled display here.
6. DC IN — connect the included power supply here.
1
2
3 4 5
6

OWC USB-C DOCK Specifications

General

Brand	OWC
Model	USB-C DOCK
Category	Docking Station
Language	English

Summary

Introduction

Minimum System Requirements

Specifies hardware and operating system requirements for using the OWC USB-C Dock.

Package Contents

Lists the items included in the OWC USB-C Dock package.

About This Manual

Provides information about potential variations in the manual and unit shipped.

Front View

Describes the LEDs, SD Card slot, Combo Audio Port, and High-Powered USB 3.1 Gen 1 Port on the front.

Rear View

Details the various ports located on the rear of the OWC USB-C Dock.

Support Resources

Connection

Guides on how to connect the OWC USB-C Dock to a computer and devices.

Usage Notes

Provides important operational details and compatibility information for the dock.

Troubleshooting

Offers steps to diagnose and resolve common issues with the USB-C Dock.

Contacting Technical Support

Lists contact methods and resources for OWC technical support.

Health And Safety Precautions

General Use Precautions
