Microstat He Manual

Microstat He Specifications

8.1 Performance

• Temperature range: 3.2 to 500 K

– May be extended down to 2.2 K (see notes)

• Temperature stability: ± 0.1 K

• System may also be run with liquid Nitrogen, temperature range 77 to 500 K

• Liquid Helium consumption at 4.2 K: < 0.45 l/hr

• Cool down consumption: 1.3 litres (nominal)

8.2 Operating Cycle

System Cooldown Specification

Room Temperature to base approx. 10 minutes with pre-cooled transfer

siphon

8.3 Physical

Parameter Nominal Value

Cryostat Weight (kg) 1.8

8.4 Electrical Power

Single Phase

1PWR-U All single phase powered units supplied with the system can be used worldwide without the need for configuration. The maximum

power consumption of each unit in this application is:

Component Power Consumption

MercuryiTC controller 450 W
