User Manual - [B]Box 6 RDM V1.2 05/2015 5/12
3. Technical specifications
Power Input AC 230V~50Hz, 0.5A
DMX Connector 3-pin and 5-pin XLR sockets
Fuse F0.5A 250V 5x20mm
Dimensions 482x135x42mm
Weight 2.25Kg
4. Product Descriptions
The B-Box 6 RDM is a 6 channel DMX/RDM booster with one DMX/RDM input and 6 DMX/RDM
outputs. This unit takes the incoming DMX/RDM signal and splits the signal into six separate
output channels. Each output channel and the input channel are completely electronically iso-
lated from each other, all six output channels have independent output drivers to boost the
DMX/RDM signal. In addition, a Link out/Terminate selector is used for secure linking when
you intend to terminate DMX/RDM signal and a RDM selector alow to enable or disable RDM
feature.
