Typical home network setup
Below you can see how a typical home network situation could be. All the devices connected to the
Wi-Fi Router can share music and you are able to access the music files from your OXX Internet Radio.
Laptop
OXX Digital
Internet Radio
PC1
PC2
Wi-Fi Router
NAS Box
