Setting shown above can fluctuate.
After applying the settings, test the machine.
The user is responsible for any incorrect planting process.
FAN (VACCUMETER SETTING)
Manometer should be arranged around
45-50 bars.
ATTENTION: Pressure value should be
50-55 bars for bigger bean seeds.
SEED SCRAPER
ATTENTION: REMOVE!!!
Scraper must not be attached.
remove
Bean Seeds
CONSIDERATIONS
1.The seeds to be used for plantation process must be dry.
2. Humid or wet seeds must not be used.
3. Sometimes seeds are wetted and are coated with a wet layer of medicine to protect
them. while planting these seeds, medicine on them sticks to the holes of the disc
and act as an obstacle for turning of the discs. So, seeding distance and seed planting
process are affected.
SEEDING COULTER
For Bean seeds, coulter depth
should be (8.5 cm).
8,5 cm
49
