DESCRIPTION OF SYMBOLS
Warning
Regulatory Compliance Mark
(RCM)
V
Volts
Hz
Hertz
~
W
/min
Alternating Current Direct Current (DC)
Ø
Diameter
U
0
Non-load voltage
U
1
Rated input voltage
U
2
On-load voltage
I
2
Current rating
X
Load duration rate
IP
Protection class
S
Used in an environment that has
high risk of electric shock
Single phase AV power &
rated frequency
Manual metal arc welding
Single phase transformer - rectifier
Wear coveralls
Do not operate in rain
Wear appropriate face shield
Wear close-toed shoes Wear welding gloves
I
1
max
Rated maximum input current
I
1
eff
Maximum effective input current
Watts
Revolutions or reciprocations
per minute
H
Insulation grade
Read Instruction Manual
Power tools that are no longer usable should not be disposed of with
household waste but in an environmentally friendly way. Please recycle
where facilities exist. Check with your local council authority for recycling
advice.
Recycling packaging reduces the need for landfill and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your local
council authority for recycling advice.
CARING FOR THE ENVIRONMENT
SPARE PARTS
Spare parts can be ordered from the Special Orders Desk at your
local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486 New Zealand 0508 069 486
E-mail: enquiries@ozito.com.au
EQUIPMENT CLASSIFICATION
Additional Specifications
I
1
max: 23.6A
I
1
eff: 9.5A
Welder Characteristics: Constant Current-Drop Characteristic
Carrying Method: Strap
Cooling System: Fan Cooling
Heating tests were conducted at ambient temperature.
Power Cable: 3 x 1.5-2mm
2
Welding Cable: 1 x 10mm
2
Recommended External Fuse: 16A.
This product is classified as Group 2, Class A welding equipment.
• Group 2 - This product generates radio frequency energy in the
frequency range 9KHz to 400GHz.
• Class A - This product is intended for use in an industrial environment.
Caution: This equipment is not intended for use in residential
environments and may not provide adequate protection to radio
reception in such environments.
