2. KEYLESS CHUCK
6
7
8
FWD
REV
2. KEYLESS CHUCK 3. CONTROLS
1. To start drilling squeeze
the variable speed
trigger.
2. To stop drilling release
the trigger.
1. Open the chuck jaws.
2. KEYLESS CHUCK
4. Pull on the bit to
ensure it is rmly
secured.
3. Tighten
the chuck
jaws.
2. Insert the
drill bit,
making sure
it is centred
in the jaws.
OPERATION
2. KEYLESS CHUCK
Variable Speed Trigger
Forward/ Reverse Lever
Installing Drill Bit
1. For forward rotation, push the fwd/rev lever hard left. For reverse
rotation push fwd/rev lever to the right.
Adjusting Torque
Turn torque ring to the desired
setting. Refer to Helpful Tips for
determing desired setting.
Removing Drill Bit
1. Fully open
the chuck
jaws then
pull out drill
bit.
Caution: Do not handle drill bits or other accessories without
gloves as they are sharp and can become hot after use, potentially
causing personal injury.
Speed Control
1. Slide the switch backward
to select rst gear.
2. Slide the switch forward to
select second gear.
2. KEYLESS CHUCK
aa
b
The gear selector controls the speed of the drill. First gear allows
slower drilling with more torque, while second gear is suitable when
less power but higher speed is required.
