ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1 Collet Nut
2 Shaft Collar
3 Spindle Lock Button
4 On/Off Button
5 Variable Speed Controls
6 Battery Release Button
7 12V Li-ion Battery
CORDLESS ROTARY TOOL
KNOW YOUR PRODUCT
1. CHANGING ACCESSORIES
8 Flexible Shaft
9 Locking Collet
10 Spindle Lock
11 Fitting Collar
12 Rotary Accessories x 81
13 Spanner
14 Charging Adaptor
15 Fast Charging Cradle
ACCESSORIES
SETUP & PREPARATION
1 2 3 4 5 6 7
8 9 10 11 12 13
WARNING! ENSURE THE TOOL IS DISCONNECTED
FROM THE POWER SUPPLY BEFORE PERFORMING ANY
OF THE FOLLOWING OPERATIONS.
1 Press and hold the spindle
lock button.
2 Unscrew the collet nut and
remove completely.
3 Select a suitable collet for
the accessory to be used
and insert. Then cover
with collet nut.
4 Lightly tighten the collet nut so
that it stays in place.
5 Insert shaft of accessory
into the collet.
6 Tighten collet nut using spindle
lock and spanner.
14 15
