Paccar MX-11 Programming Guide

PEC017
5/3/2018 Page 6 of 105
MX-11 Standard Feature
Maximum Horsepower
Maximum Torque
385 HP @ 1600 RPM
1,450 lbf-ft @ 1000 RPM
MX-11 Feature Options
Maximum Horsepower
Maximum Torque
335 HP @ 1,600 RPM
1,150 lbf-ft @ 900 RPM
355 HP @ 1,600 RPM
1,250 lbf-ft @ 900 RPM
REFUSE 355 HP @ 1,600 RPM
1,250 lbf-ft @ 900 RPM
375 HP @ 1,600 RPM
1,350 lbf-ft @ 900 RPM
400 HP @ 1,600 RPM
1,450 lbf-ft @ 900 RPM
REFUSE 400 HP @ 1,600 RPM
1,450 lbf-ft @ 900 RPM
415 HP @ 1,600 RPM
1,550 lbf-ft @ 900 RPM
MT 430 HP @ 1,600 RPM
1,450 - 1,650 lbf-ft @ 900 RPM
430 HP @ 1,600 RPM
1,650 lbf-ft @ 900 RPM

Paccar MX-11 Specifications

General

Engine Type	Diesel
Displacement	10.8 liters
Configuration	Inline 6-cylinder
Torque Range	1250-1700 lb-ft
Bore	123 mm
Stroke	152 mm
Fuel System	Common rail
Compression Ratio	17.5:1
Emission Standard	GHG17
Aspiration	Turbocharged
Emissions	SCR
Weight	2200 lbs
Coolant Capacity	40 liters
