Maintenance Procedures
5
Description
The fuel
lter / water separator module
provides ne particle ltration, water
separation, water in fuel sensing,
automatic water draining, lifetime
purication of drained water with a
charcoal lter, 12v preheating and
system manual priming in a singular
easy to service module.
NOTE
The engine and fuel module should
be operated in cold climates with
acceptable cold climate fuel blends
which noticeably reduces wax
gelling of the fuel lter cartridge. The
fuel module includes a 12 - volt pre-
heater to support preheat of the fuel
for initial start-up in mild climates.
Failure to operate with acceptable
cold climate fuel may result in insuf
-
cient fuel ow to the fuel injection
system.
Removal
1. Fuel Filter Cap
2. Fuel Filter
3. Manual Priming
Pump
4. Fuel Filter
Housing
1. Loosen the
fuel tank cap to relieve
any pressure in the fuel tank.
2. Clean the
fuel lter cap and
surrounding area to ensure dirt
does not fall in to the fuel module.
Dirt in the fuel system can lead to
signicant damage to the fuel sys
-
tem. Failure to comply may result in
equipment or property damage.
CAUTION
3. Remove the fuel lter cap by
rotating it counter-clockwise with a
wrench, automatic draining of fuel
will be initiated, wait 5 minutes for
complete fuel draining to prevent
fuel from leaking or dripping on the
starter motor
NOTE
The fuel lter cartridge is a dispos-
able lter and may not be cleaned
and reused. Dispose of the lter as
chemical waste.
4. Remove the fuel lter cartridge.
5-30
