PaceMaster Bronze XRC - Page 9

2. Assemble the Rear Stabilizer
A
STEP 2A: As shown to the Right, attach the
Rear Stabilizer (74) to the Frame (1) with Bolts
(109), Washers (113) (112) and Acorn Nuts
(110), then tighten with the included wrench
(117) or a 13mm wrench or socket.
Spring washer M8х2.0t—2PCS(112)
Washer 20х9х2.0t—2PCS(113)
M8 Acorn Nut—2PCS(110)
Bolt M8х56—2PCS
(
109
)
9
