Setup & Operation
Model Two HDCD
®
User’s Manual
Rev. C - January 2002
Factory Preset Configurations
(Suffixed values are shown only if they are different from those of the first preset listed in a column.)
_________________ PRESETS:_______________________
AD1X-24 AD+DD1X AD2X-24 DD2X-24
AD1X-16* DD1X-20* DD1X-2X* DD2X-16*
AD1X2416+ DD1X-16+ DD1X-4X** DD4X-24+
DD2X-2X+ DD4X-16^
DD2X-4X++
AD4X-24^
DD4X-4X^^
DD4X-2X~
Menu/FUNCTION: ___________________ VALUES:_______________________
Operating Mode AD_44.1 AD+DD44 AD_88.2 DD88-44
DD44-44*+ DD44-88* DD176-44+^
DD44-176**
DD88-88+
DD88-176++
AD176.4^
DD176.4^^
DD176-88~
Digital Output 1 Word Length HDCD_24 HDCD_16 HDCD_24 HDCD_24
HDCD_16*+ HDCD_20* HDCD_16*+
Output 1 HDCD_16 Dither DITHER1*+ DITHER1 ______ DITHER1*+
Digital Output 2 Word Length HDCD_24 HDCD_24 ______ HDCD_24
HDCD_16* HDCD_20* HDCD_16+^
HDCD_16+
Output 2 HDCD_16 Dither DITHER1* DITHER1 ______ DITHER1+^
Digital Output Format ______ ______ 2_WIRE ______
A/D Reference Clock INTERN INTERN INTERN ______
A/D Filter Mode NORMAL NORMAL ______ ______
Monitor Input HDCD Code Detect 24-BIT 20-BIT* 24-BIT ______
16-BIT*+ 16-BIT+ 16-BIT*(**)
Monitor Reference Clock DIG_IN DIG_IN DIG_IN ______
External Reference Clock Frequency 1X_REF 1X_REF 1X_REF 1X_REF
Monitor Digital Input Format ______ ______ 2_WIRE ______
Digital Input HDCD Code Detect ______ 24-BIT 24-BIT 24-BIT
Dig. In. HDCD_16 Decoding/DCODE16 ______ OFF ON*(**) ______
Dig. In. HDCD_16 Decoding/SCALING ______ OFF OFF ______
2X To 1X Filter Mode ______ ______ ______ NORMAL
Digital In Reference Clock ______ DIG_IN*+ DIG_IN DIG_IN
Digital Input Format ______ ______ 2_WIRE 2_WIRE
NOTE: All set-up values are stored in Presets except for System Menu PANEL, POLARITY and DAC_OPT
values, and Meter Setup Menu DISPLAY values.
