S-20 / S-20HD TRACTION, ORBITAL & S-24XM FRAME
ITEM QTY PART NUMBER DESCRIPTION
1 1 853202 FRAME, SCRUBBER, 20 TRACT
2 3 962269 SCREW, HEX, .31-18 X .75, SS
3 3 980094 WASHER, SPLIT LOCK, .31, SS
4 3 W243D WASHER, FLAT, 5/16, SS
5 1 859201 TRANSAXLE, 24VDC, 20 IN
6 1 870919 BRUSH KIT REPL FOR TRANSAXLE 859201
7 1 855206 MOTOR REPL FOR TRANSAXLE 859201
8 2 850807 BRACKET, RETAINING, TRANS
9 6 W189D SCREW, HEX, 1/4-20 X .75, SS, PATCH
10 6 920011 NUT, NYLOCK, 1/4-20, ZINC
11 2 859704 WHEEL, TRACTION, 200MM
12 2 847306 RING, RETAINING, EXT, .75
13 2 980780 WASHER, KEYED
14 2 915003 KEY, SQ, .188 X 1.31
15 2 980106 WASHER, FLAT, .25ID, 1.0OD, .12THK, SS
16 2 980002 WASHER, LOCK, SPLIT, .25
17 2 964008 SCREW, HEX, M6 X 25, SS, PATCH
18 2 857502 RIG CASTER 3INCH WITH AXLE
19 2 859709 WHEEL CASTER 3INCH
20 2 855015 ASSY CASTER 3 INCH REPLACEMENT
21 3 980079 WASHER, FLAT, .5, ZINC
22 2 980019 WASHER .50INCH SPLIT LOCK
23 2 920022 NUT HEX .50-13 ZINC
24 1 855014 ASSY VALVE SCRUBBER REPLMNT
25 1 859402 VALVE SOLENOID 24V NONADJ
26 4 S453P CLAMP, HOSE, WORM
27 1 224130 - 3.75” HOSE, 1/2” DIA X 3.75” LONG
28 1 843319 FILTER, SCREEN, BOWL
29 1 224130 - 1.56” HOSE, 1/2” DIA X 1.56” LONG
30 1 224130 - 9.50” HOSE, 1/2” DIA X 9.50 LONG
31 1 853301 FITTING, REDUCER, BM08, BM04
32 1 204179 - 19.0” HOSE, 1/4” DIA X 12.50” LONG
33 2 853802 GUIDE, SPACER, ROUND
34 2 962279 SCREW, SOCKET CAP, .31X1.0, SS
ITEM QTY PART NUMBER DESCRIPTION
35 2 920012 NUT, NYLOCK, 5/16-18, ZINC
36 1 911682 SWITCH, SNAP, BENT LEVER
37 2 W385D NUT, NYLOCK, #4-40, ZINC
38 4 980682 WASHER, FLAT, #4, ZINC
39 2 962273 SCREW, PAN, #4-40 X .88, ZINC
40 2 873804 GROMMET .50ID .81HOLE .25THK
41 1 858304 SPRING, EXTENSION
