ITEM QTY PART NUMBER DESCRIPTION
1 1 850802 BRACKET, LIFT, HEAD
2 4 855601 MOUNT, BEARING, PLASTIC
3 4 W117D SCREW, HEX, .25-20 X 2.0, SS
4 4 W104D WASHER, FLAT, .25
5 4 920011 NUT, NYLOCK, 1/4-20, ZINC
6 1 855105 LEVER, DOWNPRESSURE, DUAL
7 1 855103 LABEL, GRIP, FOOT
8 1 855004 KNOB, OVAL, .31-18
9 3 980094 WASHER, SPLIT LOCK, .31, SS
10 2 962265 SCREW, BUTTON, SOCKET, .31-18 X .75, SS
11 1 858303 SPRING, EXTENSION
12 1 853801 GUIDE, LEVER
13 1 980093 WASHER, WAVE, .50INCH
14 2 980612 WASHER, NYL, .50 X 1.25 X .062
15 1 980107 WASHER, FLAT, .31ID, 1.0OD, .12THK, SS
16 3 962279 SCREW, SOCKET CAP, .31X1.0, SS
17 2 W243D WASHER, FLAT, 5/16, SS
18 2 853802 GUIDE, SPACER, ROUND
19 2 920012 NUT, NYLOCK, 5/16-18, ZINC
20 1 980783 WASHER WAVE .75ID
S-20 / S-20HD TRACTION (DISK) & PAD ASSIST HEAD LIFT
