22 - Getting to know your computer
BASE VIEW
1
4
2
3
# Icon Item Description
1 Battery release latch
Releases the battery for removal. Insert a
suitable tool and slide to release.
2
Memory
compartment
Houses the computer's main memory.
Hard disk bay
Houses the computer's hard disk (secured
with screws).
3
Ventilation and
cooling fan
Allows the computer to stay cool.
- Do not cover or obstruct the openings.
